Product Features

• High performance ultra-reliable Lithium Iron Phosphate chemistry.
• Fully rechargeable in as little as 1.5 hours.
• Serial communication (CANBUS) compatible with leading peripherals incl. Victron®, Studer®, Ingeteam®, SMA®, Goodwe® & Sunsynk®
• On-board monitoring & diagnostics via integrated user interface / display.
• Marine-grade stainless steel enclosure.
• 10 Year product warranty.

Technical Specifications
General Information

• Battery Type: LiFePO4 (Lithium Iron Phosphate).
• Usable Capacity: 3 640Wh @C2, 25°C.
• Nominal Voltage: 13 VDC.
• Operating Voltage Range: 12 VDC ~ 13.8 VDC.
• Operating Temperature Range Charge: 0°C ~ 50°C | Discharge: -10°C ~ 50°C.
• Cycle Life @ 100% DoD @C2, 25°C: > 3 600 cycles (20% fade) | 7 000 cycles (40% fade).
• Cycle Life @ 80% DoD @C2, 25°C: > 5 000 cycles (20% fade) | 9 000 cycles (40% fade).
• Cycle Life @ 70% DoD @C2, 25°C: > 7 000 cycles (20% fade) | 12 000 cycles (40% fade).
• Dimensions (cm): 51 x 21 x 31cm (W x D x H).
• Weight (kg): 40kg.

Charge / Discharge

• Bulk Voltage: 13.8 VDC.
• Discharge Voltage (min.): 12.0 V.
• Charge Current (max.): 250A continuous.
• Discharge Current (max.): 250A continuous; 300A burst (for 1 minute max.); 750A peak (for 2 seconds max.).
• Charge Power: 3 250W continuous.
• Discharge Power: 3 250W continuous.
• Self-discharge Rate: < 2% per month.
• Charge & Discharge Efficiency: 96% @C2.
